Step Cut 25Kilogram Grain & Wheat Food Paper Bag Machine With 2.5mm - 5mm Perforation
ZT series paper tube making machine can produce multi-ply paper tube. Material paper reels being unwinding automatically, multi-layers paper tube will be formed automatically. Perforation, tearing down, tension control, deviation rectifying, counting is controlled automatically. A multi-color flexo printing machine is connected with this machine, paper tube can get 2-4 color printing.
| Brand Name: |
Tecon |
| Model Number: |
ZT9804 |
| Certification: |
CE |
| Place of Origin: |
China |
| Total Weight |
30T |
Main drive motor |
30kw |
| Size |
34.3m×2.4m×2.7m( L×W×H) |
Air consumption |
1,100L/min |
| Working hour |
22 hours/day |
Design temperature |
0~40℃ |
| Minimum Order Quantity: |
1pcs |
| Price: |
negotiation |
| Payment Terms: |
T/T or L/C |
| Supply Ability: |
16pcs per year |
| Delivery Time: |
3 months after received your payment |
| Packaging Details: |
Wooden case |
ZT9804 Tuber Machine
Operating condition
| Working hour |
22 hours/day |
| Design temperature |
0~40℃ |
| Design humidity |
MAX. 95% |
| Number required |
1 unit |
| Model name |
ZT9804 |
Performance
|
Speed
|
130~150 tubes/min(Depends on paper quality, number of ply and operators’ skill.) |
| Tube length |
670~1035 mm |
| Tube width |
420~600 mm |
| Space between tape steps |
20 mm |
| Tube Cut Length |
670~1035mm |
| Number of ply |
2~4 paper + 1 PP/PE(Please specify if you need paper bag with PP film) |
| Diameter of print roller |
ø144～ø314 mm |
| Printing width |
1300 mm(MAX) |
| Paper reel width |
860~1260 mm |
| Paper reel diameter |
Max. 1, 300 mm |
| Air consumption |
1,100L/min |
| Main drive motor |
30kw |
| Size of whole set |
34.3m×2.4m×2.7m( L×W×H) |
| Total weight |
30 T |
Automatic valve paper bag machine for Grain & Wheat
